| Business Type | Exporter, Supplier |
| Sensing Distance | Up To 400 Mm |
| Optics Resolution | 15:1 |
| Cable Length | 2 Meters |
| Click to view more | |
Product Details
Analog Output
4–20 MA
Accuracy
±1% Of Reading Or ±1.5°C
Response Time
150 Ms (95% Signal)
Power Supply
24V DC
Ambient Operating Temperature
0°C To 40°C
Temperature Range
0°C To 500°C
Monitoring
Continuous Real-Time
Measurement Type
Non-Contact
Product Description:
- Power Supply: 24V DC
- Temperature Range: 0°C to 500°C
- Non-Contact Temperature Measurement
- Sensing Distance: Up to 400 mm (Object Dependent)
- Optics Resolution: 15:1 (Distance to Spot Ratio)
- Analog Output: 4–20 mA
- High Accuracy: ±1% of Reading or ±1.5°C
- Repeatability: ±0.5% of Reading or ±0.5°C
- Fast Response Time: 150 ms (95% Signal)
- Ambient Operating Temperature: 0°C to 40°C
- Continuous Real-Time Monitoring
- High Precision Measurement
- Stable & Reliable Performance
- Suitable for Moving or Hot Objects
- Industrial Grade Design
- Easy Integration with PLC / Control Systems
- Cable Length: 2 Meters
- Low Maintenance Requirement
